Year |
2011 |
|---|---|
Make |
Mitsubishi |
Model |
FA20S Advance |
Description |
EDM Wire |
Reference # |
8069610 |
Price |
Activate Pricing |
|
This machine has been recently sold. If you are interested in a similar machine, We will be happy to locate one for you. |
|
Specifications
| X-Axis Travel |
19.6" |
|---|---|
| Y-Axis Travel |
13.7" |
| Z-Axis Travel |
11.8" |
| Control |
M750 Advance |
| U/V Axis Travel |
3" x 3" |
| Degree Taper Cutting |
15@10.25' |
| Inside Tank Dimensions |
41.34" x 31.50" |
| Power Requirement |
200-230/3/60 |
| Glass Scale Feedback |
X/Y Axis |
| Taper Unit Travel |
3.0' X 3.0' |
| Filter Tank Capacity |
187 Gallons |
| Max Workpiece |
41.34" X 31.5" x 11.61" |
| Max Workpiece Weight |
3300 Lbs. |
| Table Dims |
30.71" X 24.8" |
| Table Rapid Feed (in/min) |
51.2 |
| Resolution |
.000002 (2 Millionths) |
| Wire Diameter |
.006-.012" (0.10" Std) |
| Note |
Prepped by Mitsubishi Service Tech |
Features
|
4-Sided Table (One-Piece) |
Auto Power Recovery |
|
Auto Wire Threading |
Chiller |
|
Fast Fill Pump |
10 KG (22lb) Wire Spool |
|
Hand Pendant Controller |
Wire Alignment Gauge |
|
Wire Chopper |
Submerged Threading & Insert At Break Point |
|
Adaptive Control (Protects Against Wire Breaks/Accuracy Losses/Finish Disruptions |
Anti-Electrolysis Power Supply |
|
Auto Oiler Standard |
Ethernet Connection with FTP |
|
Filter System Paper Cartridge |
Filter Type/Precision Type 7/3 Micron |
|
Fine Hole Insert |
