Year |
2006 |
|---|---|
Make |
Kautex |
Model |
KBS20-SB |
Description |
High Performance Single Station Blow Molder for Air Ducts & Liner Production |
Reference # |
8076079 |
Price |
Activate Pricing |
|
This machine has been recently sold. If you are interested in a similar machine, We will be happy to locate one for you. |
|
Used Kautex KBS20-SB (2006) Blow Molder for Sale. This pre-owned Kautex blow molding machine is located in The United States and available to be seen under power for an inspection. If you have any questions regarding this Kautex Blow Molder, please feel free to contact us. You may Activate Pricing to view the price of this Plastic Molding Machine, or request a quote by clicking on the Inquire Now button.
Specifications
| Number of Heads |
Single Heads & Twin Head Include |
|---|---|
| Approx. Dual Head Container Size |
10 Ltr. (W. Muller Heads) |
| Head Center Spacing |
200mm Centers (7.87") |
| Approx. Single Head Container Size |
20 Ltr. (Approx. 10 Lbs. or Greater) |
| Clamping Force |
400 kN (40 US Tons) |
| Clamp Stroke |
825mm (32.48") |
| Max Mold Width |
800mm (31.49") |
| Max Mold Length |
1200mm (47.24") |
| Daylight Between Platen |
Min. 575mm (22.63") & Max. 1400mm (55.11") |
| Number of Extruders |
One (1) |
| Extruder Screw Size |
80mm |
| Extruder Horsepower |
45kw / 60 HP |
| Control |
Beckhoff |
| Power Requirement |
480v - 3Ph - 60hz (260 Amps) |
| Control Viltage |
115V |
| Note |
Molds / Tooling not Included |
Features
|
Still in Operation for Inspections |
