Year |
2022 |
|---|---|
Make |
ABB |
Model |
IRB 1300-7/1.4 |
Description |
6-Axis Articulated Industrial Robot |
Reference # |
8078854 |
Price |
Activate Pricing |
Used ABB IRB 1300-7/1.4 (2022) Robot for Sale. This six-axis robot carries a 7 Kg payload with a 1400 mm reach and repeatability of +/-0.02 mm. The compact 220 x 220 mm footprint allows mounting at any angle, and motion is managed by an OmniCore C30 controller. Axis travels are +/-180° at 230° on axis 1, +130°/-90° at 116° on axis 2, +70°/-238° at 138° on axis 3, +/-175° at 500° on axis 4, +/-120° at 415° on axis 5, and +/-400° at 687° on axis 6. Maximum TCP speed is 6.2 m/s, with a 0.5 Kg arm load. Suited to material handling, machine tending, polishing, and assembly work. Additional used robots are available, and this machine can be seen under power for an inspection. Request a Quote for further details.
Specifications
| Payload |
7 Kg |
|---|---|
| Reach |
1400 mm |
| Repeatability |
+/-0.02 mm |
| Robot Footprint |
220 x 220 mm |
| Mounting |
Any Angle |
| Control |
OmniCore C30 |
| Axis 1 |
+/-180° @230° |
| Axis 2 |
+130°/-90° @116° |
| Axis 3 |
+70°/-238° @138° |
| Axis 4 |
+/-175° @500° |
| Axis 5 |
+/-120° @415° |
| Axis 6 |
+/-400° @687° |
| Max TCP Speed |
6.2 m/s |
| Arm Load |
0.5 Kg |
| Applications |
Material Handling / Machine Tending / Polishing / Assembly |
| Note |
(2) Machines Available, Price Per Machine |
