Year |
2003 |
|---|---|
Make |
Van Dorn |
Model |
Spectra 500SP1920 |
Description |
500 Ton 43.5 oz Injection Molding Machine |
Reference # |
8078033 |
Price |
Activate Pricing |
Used Van Dorn Spectra 500SP1920 (2003) Injection Molding Machine for Sale. This 500 ton press has a 48 oz shot size, tie bar spacing of 34.9″ x 34.9″, and platen size of 49.6″ x 49.2″. Max daylight is 69″, clamp stroke is 43″, and minimum mold thickness is 14.2″. Machine control is Pathfinder 3000. Equipped with core pull, hydraulic knockout, and robot interface. Overall dimensions are 31’9″ x 7’4″ x 9′, with a weight of 53,100 lbs. The machine is under power and can be inspected running. See more used plastic injection molding machines or browse our Van Dorn inventory. Activate Pricing to view the figure, or Request a Quote for details on this press.
Specifications
| Capacity |
500 Ton |
|---|---|
| Shot Size |
48 oz |
| Tie Bar Spacing |
34.9" x 34.9" |
| Platen Size |
49.6" x 49.2" |
| Max Daylight |
69" |
| Clamp Stroke |
43" |
| Control |
Pathfinder 3000 |
| Mold Thickness |
14.2" |
| Dimensions |
31'9" x 7'4" x 9' |
| Weight |
53,100 Lbs |
Features
|
Core Pull |
Hydraulic Knockout |
|
Robot Interface |
Under Power |
