KD Machinery and the Flow Mach 500
We have handled 24 Flow Mach 500 machines, spanning build years 2017 to 2024. That is our own record, not a catalog listing.
The most common Flow Mach 500 we have handled is the Mach 500 4020 — 8 of the 24 machines.
The Flow Mach 500 variants we have handled
- Mach 500 4020 — 8 of 24
- Mach 500 4020 XD — 3 of 24
- Mach 500 4060 — 2 of 24
- Mach 500 3020 — 2 of 24
- Mach 500 2020 XD — 1 of 24
- Mach 500 4030 XD — 1 of 24
- Mach 500 4020XD — 1 of 24
- Mach 500 3020 DWJ — 1 of 24
Plus 5 in less common variants.
Specifications, from the machines we have handled
| Z-Axis Travel | 12" (1 of 24) |
|---|---|
| Table Length | 13.1' (13 of 24), 20' (4 of 24), 10.1' (3 of 24), and 4 others |
| Table Width | 6.6' (12 of 24), 6.5' (7 of 24), 10.1' (2 of 24), and 3 others |
| Control | Flow PC Based (11 of 24), Flowmaster PC Based (3 of 24), Flowmaster (2 of 24), and 7 others |
| Power Requirement | 460-480/3/60 (5 of 24), 460/3/60 (3 of 24), 480/3/60 (3 of 24), and 2 others |
What we have listed Flow Mach 500 machines at
Across 30 Flow Mach 500 machines we have listed with a published price, the middle half ran from $109,990 to $184,990, with a median of $129,990. A quarter were listed below that band and a quarter above it. These are the prices we asked, not what any machine changed hands for — condition, hours, tooling and control generation move a machine within it. Ask us where a specific one sits.
Questions buyers ask
How much does a used Flow Mach 500 cost?
Across 30 Flow Mach 500 machines KD Machinery has listed with a published price, the middle half ran from $109,990 to $184,990, with a median of $129,990. A quarter were listed below that band and a quarter above it. These are the prices we asked, not what any machine changed hands for — condition, hours, tooling and control generation move a machine within it.
Which Flow Mach 500 variant is most common?
Of the 24 Flow Mach 500 machines KD Machinery has handled, the most common variants are Mach 500 4020 (8), Mach 500 4020 XD (3), Mach 500 4060 (2), Mach 500 3020 (2), Mach 500 2020 XD (1). That is our own record of what has actually come through, not a catalog of everything the manufacturer built.
Before you buy
Which Mach fits the work?
There is no simple rule that puts a buyer on one Mach rather than another. It really depends on the size, type and thickness of the material, and what you are trying to make.
The pump is the machine
Do a minor pump rebuild when you get the pump. That way you start tracking the hours yourself and get a good idea of the intervals between rebuilds.
Hours on pumps are highly unreliable, but even pumps with over 10,000 hours are still good pumps, because by that time most big ticket items have most likely already been replaced.
What looks bad, and what is bad
Dirty tanks and slats are part of owning a waterjet. Slats in particular are maintenance items and need to be replaced periodically.
The cutting head, orifice and mixing tube are maintenance items too, with an hourly lifespan that depends on what you buy. A diamond jewel will last hundreds of hours, where a ruby or sapphire jewel will only last 20 to 40.
Getting one inspected
We always strongly recommend an inspection before you buy. KD does not perform it ourselves — the inspection is done by you, by a third-party technician, or by the OEM.
We have a network of 3rd party techs whom we can recommend. Most buyers are looking at a machine in another state or across the country, and sending a tech who is already nearby saves the travel time and cost of going to see it yourself.
Clear title
KD runs lien searches on every transaction so that our buyers can have peace of mind that they are purchasing an asset that does not have any active liens on it. We take this very seriously and are willing to pass up a deal if the seller won't cooperate on getting active liens cleared.
Where to buy a used Flow Mach 500
KD Machinery buys, sells and brokers used machinery nationwide. We have 6 used Flow Mach 500 available now, listed on this page. We have handled 24 of them, built between 2017 and 2024.
Our office is in Scottsdale, Arizona, but the machines are not. They sit wherever the seller is, across the United States, and most buyers are looking at one in another state or across the country. We arrange inspection and rigging wherever a machine stands.
Call 480.922.1674, email customerservice@kdmachinery.com, or use the quote form on any machine above. We will tell you where a specific one sits on price, what condition it is in, and can put you in touch with an inspector near it.
Flow Mach 500 machines KD has sold
KD Machinery has bought and sold 18 Flow Mach 500 machines built between 2017 and 2024.
- 2021 Flow Mach 500 4020XD
- 2017 Flow Mach 500 4020 DWJ
- 2017 Flow Mach 500 4020
- 2018 Flow Mach 500 4020
- 2019 Flow Mach 500 4020
- 2018 Flow Mach 500 3060
- 2020 Flow Mach 500 3020
- 2017 Flow Mach 500 3020
- 2021 Flow Mach 500 4020 XD
- 2024 Flow Mach 500 4020
- 2020 Flow Mach 500 4020
- 2023 Flow Mach 500 2020 DWJ
- 2018 Flow Mach 500 2060
- 2017 Flow Mach 500 4020 DWJ
- 2021 Flow Mach 500 4060
- 2018 Flow Mach 500 4020-5X
- 2020 Flow Mach 500 3080
- 2019 Flow Mach 500 4020 XD
