Make |
Cincinnati Milacron |
|---|---|
Model |
VL-850 |
Description |
850 Ton 362 oz Shot Size Injection Molding Machine |
Reference # |
8077748 |
Price |
Activate Pricing |
Used Cincinnati Milacron VL-850 Injection Molding Machine for Sale. This 850 ton press has a shot size of 362 oz, tie bar spacing of 45.3″ x 37.4″, and platen size of 66.1″ x 58.1″. Maximum daylight is 96.02″ with a minimum mold height of 44.06″, clamp stroke of 52″, and ejector stroke of 20″. Control is Mosaic. The machine was completely rebuilt by Cincinnati in 2016 and is equipped with extended daylight, core pull, hydraulic knockout, and robot interface. Additional injection molding machines and Cincinnati Milacron equipment are available. This press can be seen under power for an inspection. Activate Pricing to view the figure, or Request a Quote and we will follow up with details.
Specifications
| Capacity |
850 Ton |
|---|---|
| Shot Size |
362 oz |
| Tie Bar Spacing |
45.3" x 37.4" |
| Platen Size |
66.1" x 58.1" |
| Max Daylight |
96.02" |
| Min Mold Height |
44.06" |
| Clamp Stroke |
52" |
| Ejector Stroke |
20" |
| Control |
Mosaic |
| Note |
Completely Rebuilt By Cincinnati In 2016 |
Features
|
Extended Daylight |
Core Pull |
|
Hydraulic Knockout |
Robot Interface |
