Year |
2024 |
|---|---|
Make |
Scotpanel |
Model |
7090G2 |
Description |
Roll Former |
Reference # |
8078046 |
Price |
Activate Pricing |
Used Scotpanel 7090G2 (2024) Roll Former for Sale. This machine runs a wide C-Section at 90-mm (3.5-in.) deep by 37-mm (1.5-in.) and handles material from 0.55 to 1.2 mm (24 – 18 Ga.), with a top operating speed of 1,790 m/hr (5,900 ft/hr) — 20% more speed compared to the G1. Powertrain is a 2.2 kW (3 hp) 3-phase, 220/240V, 60 Hz drive through a 12.5:1 gearbox, with a 3,300-lb (1,500-kg) decoiler. Weight is 3,000 lb powered. Equipped with automatic in-feed coil thickness adjustment, double-rivet functionality, a 7-roller station set-up, inkjet labeling printer, plumbing hole punch toolset, region-specific service hole punch, stud end-bearing toolset, web notch toolkit, and a control laptop pre-loaded with ScotRF software. See photos for more information. Available to view under power for inspection. Activate Pricing or Request a Quote.
Specifications
| Top Operating Speed |
1,790 m/hr (5,900 ft/hr) |
|---|---|
| Wide C-Section |
90-mm (3.5-in.) deep, 37-mm (1.5-in.) |
| Thickness Range |
0.55 – 1.2 mm (24 – 18 Ga.) |
| Powertrain |
2.2 kW (3 hp) 3-Phase, 220/240V, 60 Hz |
| Powertrain Gearbox |
12.5:1 |
| Decoiler |
3,300-lb (1,500-kg) |
| Weight |
3,000 Lb (powered) |
Features
|
20% More Speed Compared to G1 |
Automatic In-Feed Coil Thickness Adjustment |
|
Double-Rivet Functionality |
Efficient 7-Roller Station Set-Up |
|
For More Information See Photos |
Inkjet Labeling Printer |
|
Plumbing Hole Punch Toolset |
Region-Specific Service Hole Punch |
|
Stud End-Bearing Toolset |
System ScotRF Software Pre-Loaded Control Laptop |
|
Web Notch Toolkit |
