Year

2022

Make

Haas

Model

GM-2

Description

CNC Vertical Machining Center

Reference #

8073799

Price

Activate Pricing

This machine has been recently sold. If you are interested in a similar machine, We will be happy to locate one for you.

Used Haas GM-2 (2022) CNC Vertical Machining Center for Sale.  This pre-owned Haas CNC vertical mill is located in The United States.  If you have any questions regarding this Haas Vertical Machining Center, please feel free to contact us.  You may Activate Pricing to view the price of this CNC Machine, or request a quote by clicking on the Inquire Now button.

Specifications

X-Axis Travel

145"

Y-Axis Travel

87.5"

Z-Axis Travel

22"

Spindle Speed

8,100 RPM

Spindle Taper

CAT 40

Spindle Motor

30 HP

Tool Magazine Capacity

30 ATC

Table Length

144"

Table Width

72"

Control

Haas CNC

Coolant

300 PSI Through Spindle Coolant

Chip Removal

Chip Auger

Table Capacity

6,000 Lbs

Rapid Traverse X/Y-Axis

1,890 IPM

Rapid Traverse Z-Axis

1,181 IPM

Cutting Feedrate

472 IPM

Approx Machine Weight

20,200 Lbs

Approx Machine Dimensions

269" x 158" x 118" Max Height

Features

Gantry Router Coolant System

Power Surge Protection

Steel Table with M12 Metric

Auxiliary Coolant Filter System

Probe Riser Block

Coordinate Rotation and Scaling

Ethernet Interface

1 GB Standard Program Memory

Renishaw Wireless Intuitive Probing System (Wips)

Rigid Tapping

Second Home Position

Side-Mount Tool Changer

Spindle Orientation

Wifi Connection For The Haas Control

Through-Tool Air Blast

Touch Screen Control

User Definable Macros

Visual Part Programming

Early Power-Failure Detection Module

Haas Connect (Remote Monitoring)

Inline Direct-Drive

Large Remote Jog Handle With Touchscreen Display

Media Display M-Code (M-130)

* Important: All machinery specifications must be independently verified by buyer. All machinery sales are subject to prior sale. Any agreement to purchase or sell machinery must be in writing.
