Year |
2018 |
|---|---|
Make |
Rohner |
Model |
Powder Coat Line |
Description |
Powder Coat Line |
Reference # |
8070755 |
Price |
$119,990 |
|
This machine has been recently sold. If you are interested in a similar machine, We will be happy to locate one for you. |
|
Rohner Powder Coat Line
Specifications
| Batch Powder Booth Exhaust |
(1) 10,000CFM Cartridge Collector Module Mounted in Rear of Booth |
|---|---|
| Batch Powder Booth Intake |
Passive Air Pulled Through Filtered Product Doors |
| Batch Powder Booth Working Dimensions |
12’ W x 12’ H x 20’ D |
| Batch Powder Booth Overall Dimensions |
12’-4" W x 12’-2” H x 24’-5" D (Includes Module Depth) |
| Batch Powder Booth Product Doors |
One Set of Filtered Product Doors, 10’ W x 10’ H Clear Opening |
| Batch Powder Booth Equipped With |
Cartridge Collector Module with Filtered Product Doors |
| Industrial Batch Oven Working Dimensions |
10' W x 10' H x 20' D |
| Industrial Batch Oven Overall Dimensions |
12’-8" W x 11’-4” H x 26’-6" D |
| Industrial Batch Oven Product Doors |
(1) Set of Insulated Product Doors 10’ W x 10’ H Clear Opening |
| Industrial Batch Oven Temperature |
160 – 450 Deg. F (500 Deg. F Maximum) |
| Industrial Batch Oven Burner Input |
1.5 Million BTUH |
| Industrial Batch Oven Product Capacity |
10,000 Pounds of Steel Per Hour |
| Industrial Batch Oven Circulation Blower |
14,000 CFM, 10HP, For a Minimum of 6.5 Air Turnovers Per Minute |
| Industrial Batch Oven Exhaust Blower |
800 CFM, .5 HP, Sized for 2 Gallons of Solvent Per Hour |
| Industrial Batch Oven Equipped With |
Return Plenum - Return Air Inlet Located at Top of Process Heater, Discharge Plenum - Two Lower Side Wall Plenums Will Discharge Heated Air Toward The Center of The Oven Creating a Mixed Flow, Process Heater - Rear Mounted |
| Industrial Blast Enclosure Working Dimensions |
12' W x 12’ H x 20’ D |
| Industrial Blast Enclosure Overall Dimensions |
12’-8” W x 12’-4” H x 24’-8” D |
| Industrial Blast Enclosure Product Doors |
(1) Set Standard Product Doors, 11’ W x 10’ H with Double Baffled Inlet Air |
| Industrial Blast Enclosure Equipped With |
Attached Dust Collector Module |
