Year |
2013 |
|---|---|
Make |
Multicam |
Model |
7-505-R |
Description |
CNC Router |
Reference # |
8078596 |
Price |
Activate Pricing |
Used Multicam 7-505-R (2013) CNC Router for Sale. This pre-owned Multicam cnc router is located in The United States and available to be seen under power for an inspection. If you have any questions regarding this Multicam CNC Router, please feel free to contact us. You may Activate Pricing to view the price of this CNC Machine, or request a quote by clicking on the Inquire Now button.
Specifications
| Number of Axis |
3 |
|---|---|
| Table Size |
120" x 145" Procss |
| Table Hold Down |
Vacuum Hold Down |
| Spindle Mfg |
(2) High-Frequency Umbra Spindles |
| Horsepower |
8.5 HP |
| Spindle Speed |
32,000 RPM |
| Tool Changer |
2 x (12) Position Carousel Style Auto Tool Changer |
| Toolholder |
HSK63 - ER40 Collets |
| Drive |
Teknic Brushless AC Servo Drive System with Matched Teknic Servo Motors |
| Control |
Multicam Handheld EZ Controller |
| Power Requirement |
208v/3ph/60amps |
Features
|
(2) 35HP 2 Stage Regenerative Vacuum Pumps |
(2) Laser Pointer Cross-Hair 12mm Red 3mW for Easy Soft Home Setting |
|
Automatic Digital Calibration & Surface Location Probes |
