Year |
2010 |
|---|---|
Make |
FOM |
Model |
FOM Blitz Alva 500M |
Description |
Miter Saw |
Reference # |
8074753 |
Price |
Activate Pricing |
Used FOM Blitz Alva 500M (2010) Other Equipment for Sale. This FOM Blitz Alva 500M offers a max cutting capacity of 19.68″ and a min cutting capacity of 12″, which can be decreased with dedicated SW. The mobile head roller table measures 94.48″, and the blade motor is rated at 2.2 Kw (2.94 HP). Workholding consists of 3 horizontal vices and 2 vertical vices on the internal side of the blade. The machine is equipped with 3 controlled axes plus pneumatic rotation of the spindle at 0 degree/90 degree/180 degree, along with an electronic profile height measuring device. It can be seen under power for an inspection by appointment. See more listings in our used saws section, use Activate Pricing, or Request a Quote for details.
Specifications
| Max Cutting Capacity |
19.68" |
|---|---|
| Min Cutting Capacity |
12" (Can Be Decreased With Dedicated SW) |
| Mobile Head Roller Table |
94.48" |
| Blade Motor |
2.2 Kw (2.94 HP) |
| Horizontal Vices |
3 |
| Vertical Vices Internal Side of Blade |
2 |
Features
|
3 Controlled Axes + Pneumatic Rotation of The Spindle 0 Degree/90 Degree/180 Degree |
Electronic Profile Height Measuring Device |
