Make |
Amada |
|---|---|
Model |
FBD8025E |
Description |
90 Ton x 8' Hydraulic Press Brake |
Reference # |
8071175 |
Price |
Activate Pricing |
Used Amada FBD8025E Press Brake for Sale. This 90 ton hydraulic press brake has an 8′ overall bed length, 86.6″ between housings, and a 15.75″ throat depth, running on a 7 HP main motor with a 14.5 gallon oil tank and 220/440/3ph power. It uses the NC9-EX control with a CNC controlled ram depth stop, and a 3 axis back gauge with 20″ of range, 3″ of R-axis travel, and back gauge speed to 1,100 IPM. Stroke is 3.94″, open height 14.57″, closed height 10.63″. Equipped with sectionalized ram clamps, upacting design, manual clamping, and manual Z axis. The machine can be seen under power for an inspection. See more press brakes or other Amada equipment, Activate Pricing, and Request a Quote.
Specifications
| Capacity |
90 Ton |
|---|---|
| Overall Length of Bed |
8' |
| Control |
NC9-EX Control |
| Distance Between Housings |
86.6" |
| Stroke |
3.94" |
| Throat Depth |
15.75" |
| Back Gauge |
3 Axis |
| Open Height |
14.57" |
| Closed Height |
10.63" |
| Power Requirement |
220/440/3ph |
| R-Axis Travel |
3" |
| Back Gauge Range |
20" |
| Back Gauge Speed |
1,100 IPM |
| Oil Tank Capacity |
14.5 Gallon |
| Main Motor |
7 HP |
Features
|
Sectionalized Ram Clamps |
Upacting |
|
CNC Controlled Ram Depth Stop |
Manual Clamping |
|
Manual Z Axis |
