Year |
2026 |
|---|---|
Make |
Glorystar |
Model |
GS-CL |
Description |
10' x 80' 40kW CNC Fiber Laser |
Reference # |
8078438 |
Price |
Activate Pricing |
Used Glorystar GS-CL (2026) Fiber Laser for Sale. This unit is configured with a 10′ x 80′ table, with table widths available from 8′ to 10′ and lengths from 41′ to 80′. Maximum wattage is 60,000, with a wattage range of 12,000 to 60,000, and the machine runs on a BOCHU CNC control with a 27″ LCD monitor. Power requirement is 380V 3-phase. Max positioning speed is 246 FPM, positioning accuracy is 0.00118″/39.4″, and repeat position accuracy is 0.00079″. Equipped with a dust collector unit, chiller unit, high-rigidity welded beam, IP51 protection rating, modular split bed structure, mortise-tenon modular table, rack and pinion dual drive, dual pallet shuttle tables, and optional bevel cutting. Available to be seen under power for inspection. See more fiber lasers, Activate Pricing, or Request a Quote.
Specifications
| Table Width |
10' |
|---|---|
| Table Length |
80' |
| Table Width Range |
8' - 10' |
| Table Length Range |
41' - 80' |
| Max Wattage |
60,000 |
| Wattage Range |
12,000 - 60,000 |
| Control |
BOCHU CNC |
| Power Requirement |
380V 3-Phase |
| Max Positioning Speed |
246 FPM |
| Positioning Accuracy |
0.00118"/39.4" |
| Repeat Position Accuracy |
0.00079" |
Features
|
27" LCD Monitor |
Dust Collector Unit |
|
High-Rigidity Welded Beam |
IP51 Protection Rating |
|
Modular Split Bed Structure |
Mortise-Tenon Modular Table |
|
Optional Bevel Cutting |
Rack & Pinion Dual Drive |
|
Chiller Unit |
Dual Pallet Shuttle Tables |
