Year |
2019 |
|---|---|
Make |
OKK |
Model |
SX-4000 |
Description |
CNC Horizontal Machining Center |
Reference # |
8075234 |
Price |
Activate Pricing |
Used OKK SX-4000 (2019) CNC Horizontal Machining Center for Sale. This machine has a 400 mm pallet measuring 15.75″ x 15.75″ with full 4th axis pallet indexing, and travels of 22.05″ in X, 22.05″ in Y, and 27.17″ in Z. The spindle is a CAT 40 taper rated to 15,000 RPM, served by a 60-tool ATC and 1,000 PSI coolant through the spindle. Control is a Fanuc 31ib. Also equipped with a chip conveyor and probes. The machine can be seen under power for an inspection by appointment. Use the Activate Pricing option to view current pricing, or browse more CNC horizontal machining centers in stock. Request a Quote for full details and availability.
Specifications
| Pallet Size (Millimeters) |
400 |
|---|---|
| Pallet Size |
15.75" x 15.75" |
| X-Axis Travel |
22.05" |
| Y-Axis Travel |
22.05" |
| Z-Axis Travel |
27.17" |
| Tool Magazine Capacity |
60 ATC |
| Spindle Speed |
15,000 RPM |
| Spindle Taper |
CAT 40 |
| Control |
Fanuc 31ib |
| Pallet Indexing |
Full 4th Axis |
| Chip Removal |
Chip Conveyor |
| Coolant |
1,000 PSI Coolant Through Spindle |
Features
|
Probes |
