Year

2015

Make

Trumpf

Model

TruLaser Tube 5000

Description

CNC Tube Laser

Reference #

8074867

Price

Activate Pricing

This machine has been recently sold. If you are interested in a similar machine, We will be happy to locate one for you.

Used Trumpf Trulaser Tube 5000 (2015) CNC Laser for Sale.  This pre-owned Trumpf CNC laser cutter is located in The United States.  If you have any questions regarding this Trumpf Laser, please feel free to contact us.  You may Activate Pricing to view the price of this CNC Machine, or request a quote by clicking on the Inquire Now button.

Specifications

Max Wattage

3,200

X-Axis Travel

255.9"

Y-Axis Travel

7.87"

Z-Axis Travel

5.90"

Control

Sinumerik 840D CNC

Laser Source

CO2

Resonator

Truflow 3200

Max. Cutting Thickness

Mild Steel 0.251" / Stainless 0.196" / Aluminum 0.157"

Max. OD Round & Rectangular Tubes

5.984"

Max. Tube Length

255.90"

Max. Length Automatic Loading

118.11"

Max. Length Finished Parts

180.0"

Max. Workpiece Weight

264.55 lbs

Max. Tube Bundle Weight

8,818 lbs

Travel Speed

3,937 IPM

Smallest Prog Increment

+/- 0.0039"

Power Consumption

27-53 Kw/H

Machine Weight

38,580 lbs

Approx. Dimensions

622”L X 319"W X 94"H

Features

15′ Unload with Scrap Conveyer

21′ Automatic Tube Loader and Magazine

Automatic Shutdown

Laser Power Control

Light Barriers & Safety Cabin

Maintenance-Free 3 Phase Servo Motors

Nitroline High Pressure Cutting

Seam Detection Camera

Teleservice Connect

TLF3200 Watt CO2 Power Source

Programmable Cutting Pressure

Chiller Unit

Dust Collector

Soft Touch Rollers

Wireless Operation Point

Work Area Lighting

* Important: All machinery specifications must be independently verified by buyer. All machinery sales are subject to prior sale. Any agreement to purchase or sell machinery must be in writing.
