Year

2015

Make

Gleason

Model

350GMS

Description

Gear Inspection System

Reference #

8068152

Price

$249,500

This machine has been recently sold. If you are interested in a similar machine, We will be happy to locate one for you.

Specifications

Nominal Workpiece Diameter

350mm

Module Range

0.4 - 18mm

Center Distance

650mm

Z Axis Travel

450mm

Cylindrical Software Standards:

PSA - 181155/181158 Analysis (French)

Cylindrical Gear Software:

(SW) GAMA SW CUSTOM TOOTH POINTING, Compare (Heat Treat Distortion), GAMA 3.0 Software, Surface Finish Software/Hardware/Rotary Probe, KIT, ADD-ON, AUTO ROTARY S.F. BEVEL, (SW) GAMA-BEVEL SURFACE FINISH MEASUREMENT, Index Eccentricity Removal, Interface QS-Stat, Interface to SPC Data Collection, Off-Axis Datum Reference Option, Tooth Contact Pattern Analysis, Cylindrical Temperature Compensation, Root Scan, Timing Relationship, Tooth Pointing Inspection, Tooth Topography

Bevel Gear Software:

Straight Bevel Inspection, Nominal Generation - Straight Bevel Gears, Spiral Bevel Temperature Compensation, HTB Operating System License

Tool Inspection Software:

Hob, Shaper Cutter, Shave Cutter

Features

Probe Tip Kit - Combination

Probe-Renishaw A-2238-0419 SP80H

Roughness Station

Spare Parts Package

Temperature Compensation

Transformer step Down 380/240

50/60Hz

UPS

Tripp-Lite 5KVA and Stand (outside US)

APC

4 station retactable 350GMS

Automatic Probe Changer

Combo Lead/Involute Master

D160 Chuck

300-650gms

LeCount MH08-/8H Mandrel Assembly

LeCount MH12-/12H Mandrel Assembly

Master Gear-Spur GMM

Part Temp Package

Magnetic Style

* Important: All machinery specifications must be independently verified by buyer. All machinery sales are subject to prior sale. Any agreement to purchase or sell machinery must be in writing.
