Year |
2013 |
|---|---|
Make |
Ganesh |
Model |
70-TTMY |
Description |
CNC Lathe |
Reference # |
8069626 |
Price |
Activate Pricing |
|
This machine has been recently sold. If you are interested in a similar machine, We will be happy to locate one for you. |
|
Specifications
| Chuck Size |
N/A |
|---|---|
| Bar Capacity |
2.75" |
| Turning Diameter |
7.48" |
| Spindle Speed |
4,000 RPM |
| Control |
Mitsubishi M720 |
| Distance Between Centers |
36.22" |
| Turret |
16 Station |
| Live Tooling |
Milling, Y-Axis |
| Sub-Spindle |
ATS Collet Chuck, Rigid Tap |
| Chip Removal |
Chip Conveyor |
| Power Requirement |
230V |
| Rotary Tool Positions |
32 Live |
Features
|
All Available Manuals |
Auto Tool Presetter |
|
Dual Turret |
Rigid Tap |
|
Parts Catcher |
Parts Conveyor |
|
20 Live Toolholders |
Simultaneous Main & Sub Spindle Machining |
|
Y-Axis |
USB Ports |
|
All Available Static Tool Holders |
ATS Collet Chuck |
|
Foot Operated Control for Chuck |
High Pressure Dual Coolant System |
|
Oil Chiller Unit |
Pcmcia Card Slot |
