Year |
2006 |
|---|---|
Make |
Anca |
Model |
RX-7 |
Description |
Tool & Cutter Grinder |
Reference # |
8068637 |
Price |
Activate Pricing |
|
This machine has been recently sold. If you are interested in a similar machine, We will be happy to locate one for you. |
|
Specifications
| Travels |
310° 360° 17.13” 17.99” 10.83” |
|---|---|
| Size Ranging |
0.4" - 3.0" diameter to 8' flute length |
| Fluting |
Capable up to 5/8" in single pass |
| Position Feedback Resolution |
0.0000039” |
| Programming Resolution |
0.000039” |
| Software Axes |
B, V, U, W. Std software for endmills, drills, and step drills |
| Max Tool Diameter |
9.4” |
| Maximum Weight |
44 Lbs |
| Spindle Power |
19 KW / 26 HP Peak Power |
| RPM |
12,000 |
| Spindle Type |
ANCA Bi-Directional |
| Spindle Drive |
Integral Direct Drive |
| Nose Taper |
ISO 30 |
| Max. Wheel Diameter |
202 Mm / 8” |
| Wheel Bore |
31.75 Mm / 1.25” |
| Wheel Packs |
2 |
| Wheels Per Pack |
Up To 4 |
| Electrical Power |
13.2 KVA |
| Weight Approx. |
9,921lb |
Features
|
Processor Pentium 4 - 2.8 Ghz |
RAM Min. 512Mb |
|
Renishaw Probe System |
56 Kbps CD Read And Write/DVD Read Only |
|
CNC System ANCA 5DX |
Colour RAL 7035 / RAL 5014 |
|
Display Touch Screen |
External Coolant System |
|
Network Ethernet |
*
Important: All machinery specifications must be independently verified by buyer. All machinery sales are
subject to prior sale. Any agreement to purchase or sell machinery must be in writing.
