Year |
1988 |
|---|---|
Make |
Cincinnati |
Model |
135 AF10 |
Description |
135 Ton x 12' Hydraulic Press Brake |
Reference # |
8077476 |
Price |
Activate Pricing |
Used Cincinnati 135 AF10 (1988) CNC Press Brake for Sale. This pre-owned Cincinnati CNC press brake is located in The United States. If you have any questions regarding this Cincinnati Press Brake, please feel free to contact us. You may Activate Pricing to view the price of this CNC Machine, or request a quote by clicking on the Inquire Now button.
Specifications
| Capacity |
135 Ton |
|---|---|
| Overall Length of Bed |
12' |
| Control |
Gen 6 Cinci |
| Distance Between Housings |
126.5" |
| Stroke |
8" |
| Throat Depth |
12" |
| Open Height |
15" |
| Closed Height |
7" |
| Approach Speed |
290 IPM |
| Form Speed |
1 to 80 IPM |
| Return Speed |
1 to 270 IPM |
| Width at Top of Bed |
4.5" |
| Main Motor |
25 HP |
| Power Requirement |
460/3/60 |
| Note |
New Gen 6 Control Retrofitted in February 2025 |
Features
|
24" 6-Axis Backgauge (X1/X2/Z1/Z2/R1/R2) |
Cylinder needs repair or replacement |
|
LaserSafe Safety Curtains |
Precision Ram Leveling With Dual Linear Glass Scale Encoders Off Load Center Compensation |
|
3-Position Electric Foot Switch |
Autocrown Deflection Compensation |
|
Control Mounted Palm Button Station |
Interlocked Construction |
|
Presence Sensing Interface |
Variable Volume Load Sensing Pump and Servo Hydraulic System |
